AMK Products Front Passenger-Side Firewall A/C Fastener Kit Camaro 1969 68-Piece

Secure the air conditioning components on the engine bay side of the passenger-side firewall in a 1969 Camaro with this 68-piece fastener kit. The application-specific collection provides factory-style hardware for multiple A/C components, replacing missing, incorrect, or worn original fasteners throughout the firewall-mounted system.

Individual hardware groups are packaged and labeled by application to help identify their intended mounting locations. The kit covers components including the evaporator, blower, condenser, receiver tank, vacuum tank, resistor, relay, hoses, wiring, brackets, and related A/C hardware.

Features and Benefits:
- 68-piece kit
- For A/C system mounting and restoration
- Hardware for engine bay side firewall
- Passenger-side hardware
- Individually packaged
- Detailed package for precise placement
- Factory-style hardware kit

Kit Includes:
- A/C ambient switch to evaporator: hex washer AB-type screws (x2pcs)
- A/C blower and evaporator to firewall: hex internal/external sems, collar stud, nuts, washer's (x10pcs)
- A/C compressor wiring: 5.1" flexible straps (x2pcs)
- A/C condenser: screws, spring nuts, well-nuts (x8pcs)
- A/C equalizer line to evaporator: 3.17" nylon strap (x1pc)
- A/C evaporator case: hex washer thread-rolling screws (x6pcs)
- A/C evaporator drain hose clamp: wire clamp (x1pc)
- A/C ground to firewall: hex washer AB screw, tooth washer (x2pcs)
- A/C heater hose to dash grommets: high-hex washer AB-type screws (x4pcs)
- A/C hose to heater hose: 11.25" flexible strap (x1pc)
- A/C radiator shield - 396, 427 or does all: hex C screws, flat washer's (x18pcs)
- A/C receiver tank to radiator support: hex washer AB screws (x2pcs)
- A/C resistor and relay to evaporator: hex washer AB-type screws (x3pcs)
- A/C vacuum hose at firewall - V8: 5.1" flexible straps (x2pcs)
- A/C vacuum tank: hex washer AB screws (x2pcs)
- A/C valve, tube brackets to evaporator: hex washer AB and AB-type screws (x2pcs)
- A/C water shut-off valve: 3/16" pop rivets (x2pcs)

Vehicle Fitment:
- 1969 Camaro
